Builder: J/Boats, Warren, RI
Designer: Rod Johnstone
Year: 2001
Hull#: 25/35
| Dimensions | ft/lbs |
|---|---|
| Length Overall | 46.00 |
| Length at Waterline | 40.50 |
| Beam | 13.80 |
| Standard Draft | 6.20 |
| Standard Ballast | 9,350 |
| Displacement | 24,400 |
| Diesel Auxiliary Engine | 75 hp |
| 100% Sail Area | 1,021 |
| I | 58.50 |
| J | 16.70 |
| P | 53.50 |
| E | 19.90 |
| Sail Area/Displacement | 19 |
| Displacement/Length | 164 |
Electronics
- Garmin (all new 2025)
- 12″ GPSMAP 8412 nav station chart plotter
- 9″ GPSMAP 923 helm plotter
- GRID 20 built into NavPod (touchscreens don’t always cooperate when wet!)
- 3x 4″ GMI 20 Marine Instruments (we’re considering adding 2 more)
- Wind wired windspeed transducer
- GMR Fantom 18x Dome Radar
- Reactor 40 Autopilot
- GHC 20 Marine Autopilot Control Unit (helm station mounted)
- Reactor Autopilot Remote Control
- Airmar DST810 Smart Multisensor (depth, speed-through-water, water temperature, boat attitude)
- ICOM IC-M424G VHF
- Vesper AIS Tranciever
Power Generation
- Solar
- 2x Maxeon MAX3-415W-R panels (830W theoretical)
- Victron MPPT charge controllers
- Northern Lights Generator
- Wind Generator (needs replacement)
Watermaker
- Spectra Catalina 300
- Output: ~12 gallons per hour
- Power: 12VDC, current draw 15 Amps
Tankage
- Diesel: 90 gallons
- Fresh water: 120 gallons
- Waste: 40 gallons (forward and aft holding tanks)
Propulsion
Sails
- Main (new 2025)
- Genoa (new 2024)
- Staysail
- Spinnaker
- Clutches 16x Spinlock XXA (new 2025)
- Lewmar Ocean Series 48, 54 and 65 winches
Engine
- 75 HP Yanmar 4JH3 diesel
- 3 blade Max Prop
Tender
Williwaw
Highfield Ultralite 310
| ft/lbs | |
|---|---|
| Length Overall | 10′ 3″ |
| Internal Length | 7′ 4″ |
| Overall Width | 5′ 8″ |
| Internal Width | 2′ 7″ |
| Dead Rise | 15° |
| Tube Diameter | 17″ |
| Number of Air Chambers | 3 |
| Max People | 5 |
| Max Load | 882 |
| Boat Weight | 110 |
| Max HP | 15 |
| Engine | Yamaha 15 HP two-stroke |
